7 Bring the shoulder straps and hoses over the face mask bag as shown.
Note: ensure that the tally and telemetry module identification numbers match and leave the tally
attached to the Bodyguard key (see image 1136800).
8 Clip the face mask bag to the cylinder retaining mechanism ‘D’ fixing using the upper bag clip
(see image 250414).
9 Bring both halves of the waist belts across the front of the shoulder straps trapping them
underneath as shown (see image 1136802).
10 Turn the set over and connect the waist belt buckles; turn set over again and pull the tabs of the
waist belts to tighten (see image 250417).
11 The waist belt buckle should be secure and lay-flat against the set backplate and the trailing end
of the cylinder strap should be fastened using the Velcro closure (see image 1136807).
12 Secure the lower face mask bag clip to the large ‘D’ ring on the waist belt.
13 The BA set is now secure and ready to be transported (see image 1136808).
14 Once wrapped place the BA set into a sealed plastic bag for transport to OSG.
