Connection to the Dräger Polytron 7000
4 Connect the plug of the external sensor (cable length 5, 15 or 30 m) to the housing
and secure by turning the ring clockwise.
5 Insert the sensor adapter into the opening of the Dräger Polytron 7000 Transmitter,
with the Dräger logo on the sensor facing the front.
6 Secure the sensor adapter with the bayonet ring.
Drilling template
NOTICE
The remote sensor is recognised automatically by the transmitter. No further
installation steps are required.
003237611.eps
4
5
6
50 ±4 mm
00423761_1.eps
90 23 761 - MA 4683.105 en
© Dräger Safety AG & Co. KGaA
Edition 05 - March 2013 (Edition 01 - September 2003)
Subject to alteration
