Dräger Savina - Core Control Functions

© Drägerwerk AG & Co. KGaA, 2019
Savina – Operating concept
Control and display unit
10
Structure of the dialog windows
1. Active ventilation mode
2. Alarm message field
3. Depending on the dialog window:
waveforms, settings, alarm limits, measured values
4. Numerical display of measured values on the main screen
5. Message field for information and instructions
1
4
2
3
5
Dashed line:
Alarm limit Paw
Dotted line:
Pressure limitation activated, set value Pmax
