Dräger Savina Short Guide

© Drägerwerk AG & Co. KGaA, 2019
Savina – Operating concept
Control and display unit
9
Keys for additional functions
1. Audio paused 2 min.: suppresses the audible alarm for 2 minutes
2. Alarm Reset: resets or acknowledges an alarm message
3. Lock: key for locking and unlocking ventilation parameters
4. Standby: activates standby mode or starts the therapy
5. Curves: displays the main screen; switches between waveform
displays
6. Changes between bright and dark screen background
7. Insp. hold.: starts manual inspiration
8. O
2
Suction: starts or terminates the suction maneuver
9. Nebul.: switches the medication nebulizer on or off
1
4
2
3
5
6
7
8
9

Dräger Savina Specifications

General

FiO2	21 - 100 %
Ventilation Modes	CPAP/ASB
Display	Color
Power Supply	100 – 240 V AC, 50/60 Hz
Patient Range	Adult, Pediatric, Neonatal
Tidal Volume Range	20 to 2000 mL
Screen Size	12.1 inch
Inspiratory Time	0.1 - 10 s
