Dräger X-AM 2500 Technical Manual

Use
Dräger X-am 2500 11
3.3 Configuration
3.3.1 Standard gas configuration
DrägerSensor Measuring range
1
Alarm A1
1)
Alarm A2
1)
threshold can be acknowledged self-latching threshold can be acknowledged self-latching
CatEx 125 PR [%LEL] 0 to 100 20 yes no 40 no yes
XXS O
2
[Vol.-%] 0 to 25
19
2
no yes 23 no yes
XXS CO [ppm] 0 to 2000 30 yes no 60 no yes
XXS H
2
S LC [ppm] 0 to 100 1.6 yes no 3.2 no yes
XXS NO
2
[ppm] 0 to 50 5 yes no 10 no yes
XXS SO
2
[ppm] 0 to 100 1 yes no 2 no yes
1) Different settings can be selected to meet customer requirements on delivery. The current setting can be checked and changed with
the Dräger CC Vision software.
A version of the CC-Vision software that can be used for Dräger X-am 2500 is available for download from the product page for the X-am 2500
at the following web address: www.draeger.com
2) With O
2
, A1 is the lower alarm threshold: an alarm is triggered if the value is too low.

Dräger X-AM 2500 Specifications

General

Operating Temperature	-20°C to +50°C
Alarm	Visual, audible, and vibration alarms
Protection Class	IP67
Weight	Approx. 220 g
Detection Principle	Electrochemical
Gases Detected	O2, CO, H2S, Ex
Detection Range	Varies by sensor type
Resolution	O2: 0.1% vol, CO: 1 ppm, H2S: 1 ppm, Ex: 1% LEL
Response Time	< 15 seconds (typical)
Humidity Range	10 to 95% RH non-condensing
Battery Life	Up to 12 hours
Power Supply	Rechargeable NiMH battery or alkaline batteries
Certifications	ATEX, IECEx
Storage Temperature	-20 to +50 °C (-4 to +122 °F)
