6. Preparing the Starter/Charger
7. Insert the axle into one of the holes at the back of the
sides of the product frame and guide it through the
housing until it emerges at the other side.
5 Fig.
8. Install a third circlip into the axle groove closest to the
product frame and slide the remaining wheel onto the
axle.
6 Fig.
(G)
9. Snap the nal circlip into the remaining groove and
push the hub cap into place.
10. Carefully tip the product back into an upright
position.
