3. Product Introduction
– 4 –
3.1 Intended Use
This product is designed to charge 12V and 24V
lead-acid, lead-acid maintenance-free, lead AGM, lead
calcium and GEL batteries and may be used to jump-start
engines of up to 2.0L petrol and 1.6L diesel. This product
requires a mains power connection to run.
Any other application beyond the conditions established
for use will be considered misuse. Draper Tools accepts
no responsibility for improper use of this product.
Important: This product is tted with a 13A. This plug is
only suitable for specic operations. For all other
operations, an appropriate plug must be tted to the
product by a qualied electrician. For more information,
see 6.1 Connecting a Plug.
WARNING! This product is not a toy and must be
respected.
Read this manual in full before attempting to assemble,
operate or maintain the product, and retain it for later
use.
Important: These instructions are intended as a guide
ONLY. ALWAYS refer to the vehicle and battery
manufacturer manuals for specic instructions relating
to the battery or vehicle as the procedure may vary. Any
manufacturer instructions relating to other equipment to
be used in the immediate area should also be consulted.
Read all instructions in full BEFORE using this product.
3.2 Specication
Stock No.: 11967
Part No.: BCSD400T
Input
Rated voltage: 220–240V AC
Rated frequency: 50Hz
Charging
Power: 1.6kW
Current 5.5A
Starting
Power: 10kW
Current: 8.0A
Output
Rated voltage: 12V/24V
Current at 12V:
Charge setting 1: 16A
Charge setting 2: 20.5A
Charge setting 3: 26A
Charge setting 4: 32A
Charge setting 5: 40A
Charge setting 6: 49A
Start (CCA): 430A
Current at 24V:
Charge setting 1: 15A
Charge setting 2: 20A
Charge setting 3: 27A
Charge setting 4: 31A
Charge setting 5: 37A
Charge setting 6: 47A
Start (CCA): 360A
Battery amperage range: 50 – 800Ah
Duty cycle (jump-starting):
3 seconds in 2
minutes, max. 5
attempts
Physical Attributes
IP rating IP20
Fuse: 2 × 110A
Time delay fuse: 115°
Charging cable length: 2m
Dimensions:
W 405 × H 615
× D315mm
Weight: 23.3kg
