ASSEMBLY Cont’d
- 9 -
7. Ensure the safety button *is in the off
position Fig.9.
8. Pull the trigger +on the lance handle
assembly to release any trapped air from the
pressure washer. See Fig.9.
9. Check that the ON/OFF switch is in the ‘O’
(OFF) position Fig.10.
10.Connect the pressure washer to the power
supply.
YOUR PRESSURE WASHER IS NOW READY FOR
USE.
5. Next connect the high pressure output hose
to the output connector as shown in Fig.8.
6. Turn the water supply ON.
Fig.8.
Fig.9.
Fig.10.
+
*
Fig.7.
4. Ensuring that the rubber sealing washer is
correctly seated inside the hose pipe
connector, connect the hose pipe to the water
inlet connector as shown in Fig.7.
NOTE MAXIMUM W
ATER TEMPERATURE 50ºC
(120ºF).
