Section 14 - Adjusting Limit Switches
Caution: The maintenance/service factory
limit setting must not be adjusted to a lower
position than the preset factory limit setting.
In addition, Draper does not recommend
setting show position at the maintenance/
service position.
PLEASE NOTE: Changing the fully open or fully closed position will reset the
electronic controls and cause the lift to operate improperly. Please call Draper
before attempting these adjustments.
Adjusting FULLY DOWN position
1.
Limit switches for the Scissor Lift are preset at the
factory. The DOWN limit switch is set for the fully down
(maintenance)
position for the size lift you have ordered.
The limit switch assembly is located inside the lift and
behind the Lifting Cable Drum.
2.
The Down limit switches shown in the drawing are for
setting the "Fully Down" position.
This can be adjusted manually by
loosening the screw to reduce the travel.
Caution: Down line switch should not be set lower
than preset factory position.
DOWN
Limit
Switch
DOWN
UP
Limit
Switch
ROTATE
TO
ADJUST
Model Closed Height Extended Height
SLX10
14
⁄
"
(35.6cm)
10'7"
(322.6cm)
SLX14
16
⁄
"
(40.6cm)
14'2"
(431.8cm)
SLX17
18
⁄
"
(45.7cm)
17'8"
(538.5cm)
SLX21
20
⁄
"
(50.8cm)
21'3"
(662.9cm)
SLX24
23
⁄
"
(58.4cm)
24'9"
(754.4cm)
SLX28
25
⁄
"
(63.4cm)
28'5"
(8 6 6.1cm)
Section 17 - Dimensions
36
3
/
16
"
(919mm)
38
5
/
16
"
(973mm)
35
9
/
16
" (903 mm)
37
11
/
16
" (957 mm)
Top View
1
/
8
"
(3.175mm)
35
7
/
16
" (900 mm)
37
1
/
16
" (941 mm)
42" (1067 mm)
36¼" (921 mm)
39
1
/
16
" (992 mm)
42" (1067 mm)
35" (889 mm)
1
9
/
16
"
(39.69mm)
Front View Side View
39
1
/
8
" (994mm) x 39
1
/
8
" (994mm)
Lipless Closure Dimensions
See
Table
A
36
3
/16"
(919mm)
38
5
/16"
(973mm)
35
9
/16"
(903 mm)
37
11
/16"
(957 mm)
Top View
1
/8"
(3.175mm)
35
7
/16"
(900 mm)
37
1
/16"
(941 mm)
42" (1067 mm)
36¼" (921 mm)
39
1
/16"
(992 mm)
42" (1067 mm)
35" (889 mm)
1
9
/
16
"
(39.69mm)
Front View Side View
39
1
/
8
" (994mm) x 39
1
/
8
" (994mm)
Lipless Closure Dimensions
See
Table
A
page 8 of 8
