Draper Targa - Hanging and Installation Methods; Wall Mounting; Suspended Mounting; Optional Mounting Brackets

2
5
/16"
5
7
/8"
5¼"
7
/8" dia.
electrical
connection
hole
3½"
Viewing
Surface
Fabric width + 7"
Case Dimensions*
Wall Mounted
Appropriate hardware
provided by installer.
Suspended
Appropriate hardware
provided by installer.
Types of Installation
Optional Ceiling Opening Trim Kit
(Dims-Side View)
2
1
/8"
2
1
/16"
4"
6
3
/4"
1
1
/16"
8"
7
/8" hole for
electr
ical
connection.
Fasteners for
wall mounting
by others.
S Hooks for
suspended
installation
by others.
Methods of Installation
6" Extension Bracket
Targa by Draper
Page 3 of 4
www
.draperinc.com (765) 987-7999
*Built-In LVC-IV will increase
overall case length by 1".
