Vigor120 Series User’s Guide
3
Interface Description
ADSL Connecter for accessing the Internet through ADSL 2+.
LAN Connecter for local networked devices.
Connecter for a power adapter.
ON/OFF: Power switch.
RESET Restore the default settings.
Usage: Turn on the router. Press the button and keep for more than 10
seconds. Then the router will restart with the factory default
configuration.
