- 16 -
3 OPERATION OF THERMOSTAT
3.1 OPERATING DEVICES OF THE HEATER
Electrical installation cover for heaters OKCE 200
Figure 10
Electrical installation covers for heaters OKCE 50, OKCE 80, OKCE 100, OKCE 125, OKCE 160 and
OKHE 80, OKHE 100, OKHE 125, OKHE 160
Figure 11
Thermostat and no other part of the control panel is not a bearing part which can be used for
any handling with the heater.
Thermostat knob Electric circuit closing indicator lamp
Tipping plastic guard
Electric circuit closing indicator lamp
Thermostat knob
