Dražice OKCE 50 - Temperature Setting

- 17 -
3.1.1 TEMPERATURE SETTING
Water temperature is set by turning the thermostat knob. The desired symbol is adjusted against the fixed
point on the control panel (Figure 12, Figure 13).
Figure 12
Figure 13
Adjusting the thermostat knob to the left backstop does not mean permanent shutoff of
the heating element. When the heater is in use without blocking the daily rate, we do not
recommend the temperature to be set above 55°C. Select the "OPTIMUM" symbol as the
maximum.
Lower limit of temp. scope
(around 5°C)
Fixed point on the control
panel
"Anti-freezing" temperature
(about 8°C)
Upper temperature range
limit (about 74°C)
"Ideal" temperature
(about 55°C)
"Ideal" temperature
(about 55°C)
Fixed mark on the
control panel
"Anti-freezing" temperature
(about 8°C)
Lower limit of temp. scope
(around 5°C)
Upper temperature
range limit (about 80°C)
