Completed Installation
Note:
The illustrations in this manual are for reference only. Please refer to the actual installation situation.
1/4" Elbow
(thin)
3/8" Elbow
(thick)
Spiral Cable
Wrap
1/4" White
Clean Water
Pipe (thin)
Clean Water Pipe Adapter Assembly
Used Water Pipe Adapter Assembly
Solenoid Valve Connector
3-Way Diverter Valve
1/4" Blue Clean
Water Pipe (thin)
Angle Valve/
Water Source
3/8" Used Water Pipe
(thick)
Pipe Fixing Clip
Controller Assembly
Floor Drain
3/8" Elbow (thick)
1/4" White Clean
Water Pipe (thin)
