Installation Instruction
❹
Connect the Controller Assembly and Power
Supply
Install the 1/4" connection locking clip
Ⓗ
in position ① - ⑦ .
Install the 3/8" connection locking clip
Ⓖ
in position ⑧ -
⑮
.
❺
Install the Connection Locking Clip
How to Disassemble a Water Pipe
Hold the snap ring and pull out the
water pipe forcefully.
Snap Ring
②
⑨
⑩
⑪
⑫
⑬
⑭
⑮
③
④
⑤
⑥
⑦
① ⑧
To Next Page
