Put dowels (n) into the holes
at each end of plinth (R).
i)
On the end of each side rail
plinth, slide in the four
dowels.
ii)
Using bolt sets (p & q)
bolt plinth (R) to the
footboard,
Do not tighten 100% yet.
iii)
n
x4
Chloe Ottoman Bed - Assembly guide - Page 14
p
x3
x3
q
r
x1
Align the ends and edges of the three plinths then
tighten all bolt sets 100% using Allen key (r).
Align & fit the wooden plinth (R) to the footboard.
Fit the angled corner brackets (F) and frame support (G).
