Make certain the bed is squared up
as shown in the diagram then tighten
all bed assembly bolts 100%.
Chloe Ottoman Bed - Assembly guide - Page 15
Double & King
Super King
H x4
H x4
S x6
I
Prepare the storage base boards - fit the eight plastic glides (I) to the
velcro pads underneath each board, then slide the boards into place.
I
S x6
Fit the cross bar (J) to
side rails (C & D).
To Next Page
