DREAMS MANHATTAN - Page 4

Stage
2
A
x16
B
x16
C
x16
Page 4 of 8
D
x1
A
B
C
2
3
3
1
FIT BOLTS TO
HEADBOARD &
FOOTBOARD
LIKE THIS.
a.
b.
&
1
2
3
3
Bed Assembly - Use Pack 'A'
MAKE CERTAIN THE BED IS
SQUARED
UP, AS SHOWN IN THE DIAGRAM
.
Once all four corners are located, make sure the bed is square as
in the sketch, then tighten all the bolts 100% using Allen key (D).
Fit the side panels
locating the brackets
behind the flat washers.
Loosely insert four bolts (A) with spring washers (B) & flat washers (C) into each side of
headboard & footboard (1&2).
Note: Do not tighten fully but leave 10mm
protruding as in the diagram.
10mm
