9
Disconnect the plug from the power source before making any
assembly, adjustments or changing accessories. Such preventive
safety measures reduce the risk of starting the tool accidentally.
Functional Description and Specifications
Model 4300 High Speed Rotary Tool
ON/OFF
SWITCH
SHAFT LOCK
BUTTON
CORD
VENTILATION
OPENINGS
HANGER
EZ TWIST™
INTEGRATED
WRENCH/ NOSE CAP
LIGHT
MODULE
LIGHT MODULE
ON/OFF SWITCH
DREMEL
CHUCK
SHAFT
Model number 4300
Voltage rating 120V 50—60Hz
Amperage rating 1.8A
Rated speed n 5,000—35,000 /min
Chuck capacity 1/32"—1/8"
FIG. 1
VARIABLE SPEED
DIAL
BRUSH COVER
(one on each side)
