Specifications
CarDAQ-Plus Specifications:
Name Value
Input Voltage Range 6VDC to 26VDC
Supply Current 320mA @ 6VDC
200mA @12VDC
170mA @15VDC
Operating
Temperature
+0C to +60C ambient
Storage Temperature -65C to +100C ambient
Size
1.25”H x 7.5”D x 5.25”W
Bus Protocols
• Primary CAN / ISO15765 / GMLAN
• Secondary CAN / ISO15765 / GMLAN (Dual or Single Wire)
• Ford SCP (J1850PWM)
• GM Class2 (J1850VPW)
• KWP2000 (ISO9141/14230)
• Chrysler SCI (J2610)
Other
• Compliant to SAE J2534 (Feb 2002) and SAE J2534-1 (Dec 2004)
• Compliant to ISO 22900-1 MVCI physical layer
• Programming voltage on J1962 pin 6, 9, 11, 12, 13, 14 or Aux
• Ground pins 9, 12, or 15
Note: Drawing current in excess of 200ma on a line configured for FEPS
programming voltage may damage the CarDAQ-Plus hardware. Avoid
grounding any output pin configured for programming voltage! Battery
Voltage is fused (auto reset) at 200mA.
