DRIFT HD Ghost Quick Guide

43
about your camera initial setup
MENU / Tag / Back Button
LEFT Button / Zoom Out
RIGHT Button / Zoom In
ACTION Button
(On/O/Rec/Stop)
Status LED
Rear Hatch
2.0” LCD Screen
300° Rotating Lens
USB Port (Mini-B)
HDMI Port (Mini-C)
3.5mm Microphone Input
Micro SD Card Slot
Battery Slot Cover
A
D
CB E
F G
H
I
J
K L
1. Unscrew and remove the
rear hatch
2. Insert a Class 6 or higher
micro SD card
3. Lift the hinged battery
slot cover and insert the
battery as shown (below)
4. Connect the camera
via mini USB cable to a
powered USB port and
charge the battery for 4
hours before first use
5. Replace the rear hatch
and screw shut to secure

DRIFT HD Ghost Specifications

General

Video resolutions	1280 x 720, 1280 x 960, 1920 x 1080 pixels
Maximum frame rate	120 fps
Supported video modes	1080p, 720p, 960p
Video formats supported	H.264, MOV, MP4
Maximum video resolution	1920 x 1080 pixels
Photo mode	Yes
Sensor type	CMOS
Light exposure modes	Auto, Manual
Display diagonal	2 \
USB connector type	Mini-USB B
USB 2.0 ports quantity	1
Internal memory	0.256 GB
Compatible memory cards	microSD (TransFlash), microSDHC
Maximum memory card size	32 GB
GPS (satellite)	No
Product color	Black
Protection features	Water resistant
Battery voltage	3.7 V
Battery capacity	1700 mAh
Battery life (max)	- h

Weight and Dimensions

Depth	33 mm
Width	52 mm
Height	105 mm
Weight	167 g
