8
ASSEMBLY INSTRUCTIONS
FULL-ELECTRIC AND
SEMI-ELECTRIC BED
Both ends of the hi/lo rod assembly
have a slot to mount on the foot end
and head end gearbox shaft pins (see
picture at right). Follow steps 2-3 to
mount the hi/lo rod assembly on the
gearboxes.
2. Connect the hi/lo rod assembly to
the bed: Attach either end of hi/lo rod
assembly to the foot end gearbox.
3. Attach other end of hi/lo rod
assembly to head end gearbox.
