Ambassador Electric Scooter Page 7 of 16 Owner’s Handbook (Code: Ambassador_IFU)
Tiller Adjustment
The tiller can be adjusted into several positions.
1. Push (or pull) the lever on the scooter tiller
(shown below) to adjust the tiller to the position
you require.
2. Release the lever to lock the tiller.
Circuit Breaker.
The circuit breaker may trip when the scooter is
under excessive load or when travelling on steep
inclines. It will be more prone to tripping when the
scooter is low on battery charge. Under normal
conditions the circuit breaker button will protrude
by 2mm – 3mm. If the circuit breaker has tripped the
button will protrude by 7mm. To reset the circuit
breaker, push the button in and the scooter should
operate as normal.
The circuit breaker is located on the left hand side
of the rear of the frame, behind the back bumper.
Freewheel Lever
The freewheel levers allows the automatic brake to be
disengaged so the scooter can be manually pushed
and/or manoeuvred. When in freewheel mode the
brakes are not applied so it should not be used when:
1. Somebody is sat on the scooter
2. If the scooter is left unattended
3. When the scooter is on a gradient
Engaged (Drive) Mode:
Push the lever UP completely and the scooter can be
driven by the motor.
Freewheel Mode:
Pull the lever DOWN and switch the scooter off. The
scooter can now be pushed / moved manually.
Warning
The lever should only be set to
FREEWHEEL when on flat ground and
unoccupied by the user. Otherwise, there
is a risk of damage or injury.
