You can adjust the amount of legroom on the
scooter by sliding the seat back and forth. To
slide the seat, lift up the seat sliding handle (B).
Then adjust the seat to correct position, release
the handle and continue sliding the seat until it
locks in position.
To alter the backrest angle, pull up on the seat
recline lever, then adjust the backrest to the
required position and release the lever. Please
note if nobody is using the backrest when the
lever is operated, it will automatically spring the
backrest forward to fold the seat.
Armrest Adjustment. To adjust the angle of the
armrest, first flip up the armrest. Then turn the
wheel located underneath the armrest pad to adjust
to the armrest angle when lowered in to position.
Tiller Adjustment
The tiller can be adjusted into several positions.
1. Push (or pull) the lever on the scooter tiller to
adjust the tiller to the position you require.
2. Release the lever to lock the tiller.
Circuit Breaker. The circuit breakers may trip when
the scooter is under excessive load or when
travelling on steep inclines. They will be more prone
to tripping when the scooter is low on battery
charge. Under normal conditions the circuit breaker
buttons will protrude by 2mm – 3mm. If the circuit
breakers have tripped the buttons will protrude by
7mm. To reset the circuit breakers, push the buttons
in and the scooter should operate as normal.
Freewheel Lever
The freewheel levers allows the automatic brake to be
disengaged so the scooter can be manually pushed
and/or manoeuvred. When in freewheel mode the
brakes are not applied so it should not be used when:
1. Somebody is sat on the scooter,
or
2. If the scooter is left unattended,
or
3. When the scooter is on a gradient
Warning
The lever should only be set to
FREEWHEEL when on flat ground and
unoccupied by the user. Otherwise, there
is a risk of damage or injury.
