Your scooter requires assembly prior to initial use. Please be sure to follow these steps
to properly set up your scooter.
Step 1:
Using a phillips head screwdriver,
remove the 4 screws securing the rear
shroud to the base of the scooter.
Step 2:
Disconnect the two plastic harnesses
connecting the tail lights on the rear
shroud to the base of the scooter.
Step 3:
Connect the batteries by connecting the
black battery harnesses shown to the
right.
