INSPECTION AND MAINTENANCE
DISASSEMBLING THE SCOOTER
The Stingray can be disassembled to 4 pieces. The seat, front section, rear section and
battery. Follow these steps to disassemble.
1. Switch the scooter off, unscrew the seat knob and remove pin. Pull up on seat to
remove.
2. Open battery door, pull out battery by strap. Disconnect the batteries by disconnecting
both connectors.
3. Loosen tiller adjustment knob and lower tiller. Retighten bolt when lowered.
4. Step on rear section frame until the lower pegs are no longer in the curved, locking
brackets. Remove cable from battery.
25
12
3
4
