28
SPECIFICATION
MODEL REFERENCE STINGRAY
DIMENSION 38" X 24" X 37 "
(L X W X H)
WEIGHT(KG),W/I BATTERY 84 LBS
W/O BATTERY 63 LBS
PROPULSION MOTOR 270W X 1
BATTERY 12V12AH X 2
CHARGER DC24V 2A
FRONT TIRE 2.5-4 X 1
REAR TIRE 2.5-4 X 2
DRIVING SYSTEM Direct drive the rear wheels
(with differential gear)
BRAKE SYSTEM Electromagnetic brakes
CONTROL METHOD By speed control lever
TOP SPEED (FORWARD) 4 MPH
REVERSE 3 MPH
CLIMBING ANGLE 8º
CRUISING RANGE (SEE NOTE) 20 MILES
MIN. TURNING RADIUS 32”
GROUND CLEARANCE 2.2 ”
MAX. LOAD WEIGHT 250 LBS.
(INCLUDING GOODS)
REMARK: Drive reserves the right to modify the specification if necessary. The final
specification is subject to the individual scooter you purchase from your dealer.
NOTE: Maximum driving distance is based on an ambient temperature of 68°F, a 165 lb.
driver and a brand new fully charged battery by a constant driving speed at 4mph with
70% battery power discharged.
