Installation
Location
1. Carefully remove the plastic frame from the front panel of the unit.
2. Fix the unit in place with the 4 included #8 pan head self-tapping screws.
3. Replace the plastic from on the front panel of the unit.
• Choose a mounting location away from humid areas, water sources, burning products or any equipment
that can radiate heat.
• Select an area on the wall or cabinet, which is free from cable, fuel or brake lines.
• Ensure when the stereo is mounted in the cut out that the wires at the rear of the unit are not pressed
against the heat sink.
Installing the unit
• Before nally installing the unit, connect the wiring temporarily and make sure the unit and the system
function properly.
• Fix the unit to the wall using 4 self-tapping screw as indicated in the illustration.
Screw
Screw
Plastic frame of
the front panel
4
