DROPSA SMART3 User Manual

11
6.4.2 Full automatic version- 3133806*
 TYPE 2
6.4.3 “Smart & Simple” AND AUTOMATIC VERSION - 3133807
 TYPE 1
A (DIN43650)
B (DIN40050)
PIN
DESCRIPTION
PIN
DESCRIPTION
1
AC / DC POWER INPUT
1
Alarm Relay –
Common
2
2
Alarm Relay - NC
3
NOT USED
3
Alarm Relay - NO
4
Earth
4
NOT USED
A (DIN43650)
C (M12X1)
D (M12X1)
PIN
DESCRIPTION
PIN
DESCRIPTION
PIN
DESCRIPTION
1
AC / DC
POWER INPUT
1
Alarm Relay –
Common
1
Power counter
+ **
2
2
Alarm Relay -
NC contact
2
Counter (N / P)
/ INPUT
suspend
3
NOT USED
3
Alarm Relay -
NO contact
3
Power counter
-
4
Earth
4
4
NOT USED
5
NOT USED
** For 24V versions the output supply is 24Vdc
*APPLICABLE TO PUMP CODES:
4011019/4011119/4011219/4011319/4011419/
4011519/4011619/4011719
*APPLICABLE TO PUMP CODES:
4011018/4011118/4011218/4011318/4011418/
4011518/4012018/4012118/4012218/4012318/
4012418/4012518/4011618/4011718/4012618/
4012718
ALARM
CONTACT
BI-STABLE
RELAY
BI-STABLE
RELAY
