DROPSA SMART3 - Electrical Connections - Manual Versions (Type 2); Type 2 (Optical Level N & Pressure Switch); Type 2 (Optical Level P & Pressure Switch)

8
 TYPE 2
- FOR MANUAL VERSIONS WITH PRESSURE SWITCH SIGNAL AND OPTICAL LEVEL (N) *- 3133803
- FOR MANUAL VERSIONS WITH PRESSURE SWITCH SIGNAL AND OPTICAL LEVEL (P)* - 3133805
A (DIN43650)
C (M12X1)
D (M12X1)
PIN
DESCRIPTION
PIN
DESCRIPTION
PIN
DESCRIPTION
1
AC / DC
POWER INPUT
1
Push Button
Contact (Voltage
Free)
1
Level Sensor
Power supply +
2
2
2
Level Sensor
Power supply -
3
NOT USED
3
NOT USED
3
NOT USED
4
Earth
4
4
PNP Alarm
Output of level
5
PNP signal of
pressure switch
A (DIN43650)
C (M12X1)
D (M12X1)
PIN
DESCRIPTION
PIN
DESCRIPTION
PIN
DESCRIPTION
1
AC / DC
POWER
INPUT
1
Push Button
Contact (Voltage
Free)
1
Level Sensor
Power supply +
2
2
2
Level Sensor
Power supply -
3
NOT USED
3
NOT USED
3
NPN Alarm
Output of level
4
Earth
4
4
NPN signal of
pressure switch
5
NOT USED
*APPLICABLE TO PUMP CODES:
4010013/4010113/4010213/4010313/4010413/
4010513/4010613/4010713
Optilev
level
sensor
REMOTE
BUTTON
CONTACT
Button
push
to made
Open on
pressure
LEVEL
PNP
PRESSURE
SWITCH
PNP
REMOTE
BUTTON
CONTACT
Optilev
level
sensor
Button
push
to made
Open on
pressure
* APPLICABLE TO PUMP CODES:
4010015/4010115/4010215/4010315/4010415/
4010515/4010615/4010715
For4010225-4010525 pumps the PS is close on
pressure
PRESSURE
SWITCH
NPN
LEVEL
NPN
12V
24V
4
5
4
5
