DROPSA SMART3 User Manual

9
 TYPE 3
- FOR MANUAL VERSIONS WITH NC SERIES ALARM*- 3133801
- FOR MANUAL VERSIONS WITH NO SERIES ALARM*- 3133801
A (DIN43650)
D (M12X1)
PIN
DESCRIPTION
PIN
DESCRIPTION
1
AC / DC POWER INPUT
1
Common
2
2
Level alarm
3
NOT USED
3
Pressure Switch Contact
4
Earth
4
Push Button Contact
(Voltage Free)
5
*APPLICABLE TO PUMP CODES:
4010001/4010101/4010201/4010301/4010401/
4010501/4010601/4010701
Button
push
to made
Open on
low level
Open on
pressure
REMOTE
BUTTON
CONTACT
Button
push
to made
Open on
low level
Close on
pressure
A (DIN43650)
D (M12X1)
PIN
DESCRIPTION
PIN
DESCRIPTION
1
AC / DC POWER INPUT
1
Common
2
2
Level alarm
3
NOT USED
3
Pressure Switch Contact
4
Earth
4
Push Button Contact
(Voltage Free)
5
*APPLICABLE TO PUMP CODES:
4010621/4010721/4010021/4010121/4010221/
4010321/4010421/4010521
REMOTE
BUTTON
CONTACT
COMMON
LEVEL
ALARM
PRESSURE
SWITCH
CONTACT
COMMON
LEVEL
ALARM
PRESSURE
SWITCH
CONTACT
