Mounting the frame and front
The frame and front are packed separately to the basic set.
Fit the frame to the interior with the 4 self-tapping screws
(13), ( figs. 13 and 14).
Hang the front onto the interior with the hooks (14)
(figs. 15 and 16).
Nederlands
INSTRUCTIONS FOR INSTALLATION
19
Romano
A
A
SECTION A-A
38c-1101
fig. 16
14
fig. 12
fig. 14
fig. 11
fig. 13
fig. 15
13
14
13
12
12
