16
Keypad Quick Guide
Status Lights
Ready - must be on to arm system. All zones must be secured or bypassed and the
system disarmed for this light to activate.
Armed - indicates system is armed. If the Ready light and the Armed light are both on
it indicates an Exit Delay is in progress.
Trouble - On indicates a system malfunction or tamper. Flashing - Indicates that the
keypad has a low battery condition. Follow the instructions displayed or enter
to view trouble. The Trouble light will turn off when the trouble is corrected.
AC Power - indicates AC Power is present. The AC Power light will turn off when AC is
absent.
Function Keys
Stay Arms the system in Stay Mode.
Away Arms the system in Away Mode.
Chime
Same as pressing on the keypad.
Bypass
Same as pressing on the keypad.
Quick Exit
Same as pressing on the keypad.
Special Keys
Language Selection - Press and hold both buttons simultaneously for 2 seconds to acti-
vate. Scroll to the desired language. Press to select choice.
Fire - Press and hold for 2 seconds to activate.
These keys must be
programmed by the
installer to function.
Auxiliary - Press and hold for 2 seconds to activate.
Panic - Press and hold for 2 seconds to activate.
User Commands
Press to select, press to scroll, press to exit.
PRESS... To ...
Bypass Zones
Press
Clear Bypass
Press
Bypass Recall
Press
Save Bypass
Press
Recall Save
View System Troubles Scroll to view all troubles
View Alarms in Memory Scroll to view alarms
Chime ON/OFF Turns chime on and off
