17
SYSTEM AREASYSTEM AREA
SYSTEM AREASYSTEM AREA
SYSTEM AREA
COMMUNICATORCOMMUNICATOR
COMMUNICATORCOMMUNICATOR
COMMUNICATOR
REPORTING CODESREPORTING CODES
REPORTING CODESREPORTING CODES
REPORTING CODES
If a user enters too many incorrect access codes (see “Total Bad Codes” under “Keypad Lockout
Options” for programming the number of incorrect code entries), the keypad will be locked out,
preventing anyone from attempting to enter any more access codes. When keypad lockout occurs, the
keypad lockout reporting code is sent to the central station.
Reporting Codes for Openings.
Reporting codes for users 0001-0128. See “Miscellaneous Openings” for additional users.
Miscellaneous Reporting Codes for Openings.
Opening 129 - 1000 - This reporting code will be sent when any user code from 0129-1000 is used to
disarm an area. In order to identify the user which disarmed the area the panel will first perform a
“User Log” for the user, and then log/transmit the Opening 129-1000 reporting code.
Miscellaneous Reporting Codes for Openings.
Opening After Alarms Reporting Code -The system sends this code to the central station when the
system is disarmed after there was an alarm.
Open Automatic - This reporting code will be sent any time an area on the system is autodisarmed.
The system sends this reporting code when area(s) are opened by the APS software.
The system sends this reporting code when area(s) are opened by the ODS software.
System Maintenance Reporting Codes. There are 27 reporting codes for events relating to the operation and
maintenance of the system. The reporting codes are:
• Battery Trouble and Battery Restoral - If the battery voltage on the PC6010 main panel is weak,
disconnected or if the battery fuse fails, a battery trouble occurs, and the battery trouble reporting code is
sent. When the battery voltage and fuse are restored, the battery restoral code is sent. See the “Viewing
Fault Conditions” section in the System Manual.
• AC Line Trouble and AC Line Restoral - If the incoming AC voltage to the AC terminals fails, an AC
trouble occurs and the AC trouble reporting code is sent to the central station after the AC Fail Tx Delay
has elapsed (see “AC FAIL TX DELAY”). When the incoming AC is restored, the AC restoral reporting code
is sent to the central station. See the “Viewing Fault Conditions” section in the System Manual.
• Main Bell Trouble and Main Bell Restoral - If a bell trouble occurs, either from the bell fuse failure or the
open bell terminals, the Main Bell Trouble reporting code will be sent to the central station. When the
trouble condition is restored, the Main Bell Restoral reporting code will be transmitted.
• Main Aux Trouble and Main Aux Restoral - If an auxiliary voltage supply trouble occurs, the Main Aux
Trouble reporting code is transmitted, and when the auxiliary voltage supply is restored, the Main Aux
Restoral code is transmitted.
• Ebus Low Power and Ebus Low Power Restoral - When a module on the system has low power, the
Ebus Low Pwr reporting code will be transmitted. When the power is fully restored, the Ebus Restoral
reporting code will be sent.
• Ebus Comm Fault and Ebus Comm Restoral - When the system loses communication with a module, the
Ebus Trouble reporting code will be transmitted, and when communications resume the Ebus Restoral
reporting code will be sent.
• Backbone Trouble and Backbone Restoral - When the system loses communication with a backbone
module, the Backbone Trouble reporting code will be transmitted, and when communications resume the
Backbone Restoral reporting code will be sent.
• TLM Failure - A TLM reporting code will be sent over the backbone when a TLM trouble occurs.
OPEN AFTER ALARMOPEN AFTER ALARM
OPEN AFTER ALARMOPEN AFTER ALARM
OPEN AFTER ALARM
OPEN AUTOMATICOPEN AUTOMATIC
OPEN AUTOMATICOPEN AUTOMATIC
OPEN AUTOMATIC
6442 APS OPENING6442 APS OPENING
6442 APS OPENING6442 APS OPENING
6442 APS OPENING
SYSTEM MAINTSYSTEM MAINT
SYSTEM MAINTSYSTEM MAINT
SYSTEM MAINT
(10)(10)
(10)(10)
(10)
OPENINGSOPENINGS
OPENINGSOPENINGS
OPENINGS
(08)(08)
(08)(08)
(08)
USERS 1-128USERS 1-128
USERS 1-128USERS 1-128
USERS 1-128
MISC OPENINGSMISC OPENINGS
MISC OPENINGSMISC OPENINGS
MISC OPENINGS
(09)(09)
(09)(09)
(09)
OPENING 129-1000OPENING 129-1000
OPENING 129-1000OPENING 129-1000
OPENING 129-1000
KEYPAD LOCKOUTKEYPAD LOCKOUT
KEYPAD LOCKOUTKEYPAD LOCKOUT
KEYPAD LOCKOUT
6443 ODS OPENING6443 ODS OPENING
6443 ODS OPENING6443 ODS OPENING
6443 ODS OPENING
