26
if unsuccessful, the panel will try to call using the land lines on
the next dialing attempt
This process will continue until the panel has successfully
communicated with the central station or until the panel’s pro-
grammed number of dialing attempts have been exhausted.
Using the LINKS as a Redundant Communicator
The panel can be programmed to call using first the
LINKS1000 and then the land line when an event occurs. To
program this option, select both the telephone number and
the LINKS options for the Communicator Call Direction
Options for the event. The Call LINKS as well as Land Line
option must be selected.
LINKS Special Preamble
In some areas of North America, dialing #DAT or *DATA
reduces the cellular billing increment. The LINKS Special
Preamble (section [393]), allows the use of [*] and [#] charac-
ters for the programming of #DAT and *DATA.
The LINKS Special Preamble is sent BEFORE the Preamble
programmed in Sections [390] to [392].
Example: [Special Preamble][Regular Preamble][Telephone
Number]
NOTE: If this Special Preamble is programmed, it will be
inserted before the Regular Preamble of ALL telephone num-
bers. Hex digits D and E are not supported for Preamble pro-
gramming.
NOTE: If Busy Tone Detection is enabled, the LINKS1000
must be tested to ensure full operation.
Please refer to the LINKS1000 installation Manual for more
information and connection diagrams.
LINKS Preamble (First Telephone Number) . . . Section [390]
LINKS Preamble (Second Telephone Number). Section [391]
LINKS Preamble (Third Telephone Number). . . Section [392]
LINKS Preamble
(Downloading Telephone Number) . . . . . . . . . . Section [490]
Communicator Call Direction Options. . . Section [361]-[368]
Call LINKS as well as Land Line . . . . . . . . .Section [380]: [7]
LINKS Special Preamble. . . . . . . . . . . . . . . . . . Section [393]
*Not investigated by UL
5.27 Additional System Modules
The following modules are programmed through the module
programming sections [801]-[804]: the PC5400 Printer mod-
ule, the Links2X50 Long-Range Radio module, the Skyroute
transceiver module, and the PC5132 Wireless Receiver and
all of its devices. For instructions on the installation and pro-
gramming of these additional modules and devices, please
see their respective installation and programming manuals.
PC5400 Printer Module Programming. . . . . . . . Section [801]
Alternative Comm. (LINKS2X50, Skyroute)
Programming. . . . . . . . . . . . . . . . . . . . . . . . . . . Section [803]
PC5132 Programming. . . . . . . . . . . . . . . . . . . . Section [804]
5.28 Resetting Factory Defaults
On occasion, it may be necessary to default the main control
panel or one of the connected modules: the LINKS2X50 Radio
interface, Skyroute module, the PC5132 wireless receiver, and
the PC5400 Printer module.
To default the main control panel (hardware), perform the fol-
lowing:
1. Remove AC and battery from the panel.
2. Remove all wires from the Zone 1 and PGM1 terminals.
3. With a piece of wire short the Zone 1 terminal to the PGM1
terminal.
4. Apply AC power to the main panel.
5. When Zone Light 1 is lit on the keypad the default is com-
plete.
6. Remove AC power from the control
7. Reconnect all original wiring and power up the control.
NOTE: AC power must be used to power the panel. The panel
will not default if only the battery is used.
To default the main control panel software and other modules,
perform the following:
1. Enter the Installer’s Programming mode.
2. Enter the appropriate programming section [XXX].
3. Enter the Installer’s Code.
4. Re-enter the appropriate programming section [XXX].
The panel will take a few seconds to perform the default.
When the keypad is again operational the default is complete.
NOTE:If using Identified Wireless Keys (PC5132 v3.0 or later
only), when the main panel is defaulted, all wireless key
access codes must be re-programmed. Refer to your PC5132
v3.0 Installation Manual for more information.
Restore Alternative Communicator
(LINKS2X50, Skyroute)
to Default Programming.. . . . . . . . . . . . . . . . . . Section [993]
Restore PC5132 to Default Programming. . . . . Section [996]
Restore PC5400 Printer to Default ProgrammingSection [997]
Restore Panel to Default Programming. . . . . . . Section [999]
5.29 Installer’s Lockout
If Installer’s Lockout is selected, a hardware default cannot
be performed. If a software default is performed, all program-
ming will restore to factory default.
If Installer’s Lockout Disable is selected, the panel will
restore all programming to factory defaults when a hardware
or software default is performed on the main control panel.
To enable or disable Installer’s Lockout, perform the following:
1. Enter the Installer’s Programming mode.
2. Enter the appropriate programming section: [990] or [991].
3. Enter the Installer’s Code.
4. Re-enter the appropriate programming section: [990] or
[991].
Installer Lockout Enable . . . . . . . . . . . . . . . . . . Section [990]
Installer Lockout Disable . . . . . . . . . . . . . . . . . Section [991]
5.30 Walk Test (Installer)
The Installer Walk Test can be used to test the alarm state of
each zone of the panel. The walk test cannot be used to test
zone type [24].
Before beginning the walk test, ensure the following condi-
tions are met:
1. The panel is disarmed
2. The Keypad Blanking option is disabled (section [016]:
[3])
3. The Fire Bell is Continuous option is disabled (section
[014]: [8])
4. The Transmission Delay is disabled, if Transmission
Delay is not required (section [370])
NOTE: Fire Troubles are not supported in Walk Test.
