DSC PC1555

34
Advanced System Programming
Zone Attributes (Section 5.3 “Zone Attributes” on page 16)
Zone Attribute Defaults (Y = Option ON; N = Option OFF):
*NOTE: For UL installations, do not change attribute 5 (Force Arming) from the default setting.
Section Zone # Zone 1 2 3 4 5 6 7 8
Type*
[101] 1 ( )
I________I I________| I________| I________| I________| I________| I________| I________I
[102] 2 ( ) I________I I________| I________| I________| I________| I________| I________| I________I
[103] 3 ( ) I________I I________| I________| I________| I________| I________| I________| I________I
[104] 4 ( ) I________I I________| I________| I________| I________| I________| I________| I________I
[105] 5 ( ) I________I I________| I________| I________| I________| I________| I________| I________I
[106] 6 ( ) I________I I________| I________| I________| I________| I________| I________| I________I
[107] 7 ( ) I________I I________| I________| I________| I________| I________| I________| I________I
[108] 8 ( ) I________I I________| I________| I________| I________| I________| I________| I________I
[109] 9 ( ) I________I I________| I________| I________| I________| I________| I________| I________I
[110] 10 ( ) I________I I________| I________| I________| I________| I________| I________| I________I
[111] 11 ( ) I________I I________| I________| I________| I________| I________| I________| I________I
[112] 12 ( ) I________I I________| I________| I________| I________| I________| I________| I________I
[113] 13 ( ) I________I I________| I________| I________| I________| I________| I________| I________I
[114] 14 ( ) I________I I________| I________| I________| I________| I________| I________| I________I
Attribute: 123456 7 8
ON Audible Steady Chime Bypass Force* Swing Tx. Delay Wireless Zn.
OFF Silent Pulsed No No No No No No
Zone Type:
00 Null Zone NNNNNN N N
01 Delay 1 YYYYN Y N N
02 Delay 2 YYYYN Y N N
03 Instant YYYYN Y N N
04 Interior Y Y N Y N Y N N
05 Int. Stay/Away Y Y N Y Y Y N N
06 Dly. Stay/Away Y Y N Y Y Y N N
07 Dly. 24hr Fire (Hardw.) Y NNNNN N N
08 Stand. 24hr Fire (Hardw.) Y NNNNN N N
09 24hr Superv. N Y N N Y N N N
10 24hr Superv. Buzzer N Y N Y N N N N
11 24hr Burglary Y Y N Y N N N N
12 24hr Holdup N Y NNNN N N
13 24hr Gas Y NNNNN N N
14 24hr Heating (N/C zone) Y NNNNN N N
15 24hr Medical Y Y NNNN N N
16 24hr Panic Y Y NNNN N N
17 24hr Emergency Y Y NNNN N N
18 24hr Sprinkler Y Y NNNN N N
19 24hr Water Y Y NNNN N N
20 24hr Freeze Y Y NNNN N N
21 24hr Latching Tamper Y Y NNNN N N
22 Momentary Keyswitch NNNNY N N N
23 Maintained Keyswitch NNNNY N N N
24 LINKS Answer NNNNY N N N
25 Interior Delay Y Y N Y N Y N N
87 Dly. 24hr Fire (Wireless) Y NNNNN N Y
88 Stand. 24hr Fire (Wireless) Y NNNNN N Y
