1
System Introduction
S E C T I O N 1
1.1 PC5015 Specifications
Flexible Zone Configuration:
8 Fully Programmable Zones
38 Access Codes: 32 User, 1 System Master, 2 Partition Master, 2 Duress and 1 maintenance
Expandable to 32 Zones
Keypads with zone inputs available (PC5508Z, PC5516Z, PC5532Z, LCD5500Z)
Hardwired expansion available using the PC5108 Eight Zone Expansion Module and the PC5700 Fire
Module
Wireless expansion available using the PC5132 Wireless Zone Expansion Module (up to 32 wireless
zones, 900MHz, True Spread Spectrum Technology, Fully Supervised)
Normally Closed, Single EOL, or Double EOL zone supervision
28 Zone Types, 8 Programmable Zone Options
2 Partitions
Audible Alarm Output:
700mA Supervised Bell Output (current limited at 3 amps), 12 V
DC
Steady or Pulsed Output
EEPROM Memory:
Will not lose programming or system status on complete AC and Battery failure
Programmable Outputs:
Up to 14 Programmable Voltage Outputs, 24 programmable options
One Low Current (50 mA) PGM output on main panel
One High Current (300 mA) PGM output on main panel
Eight Additional Low Current (50 mA) PGM outputs available using the PC5208 module
Four High Current (1 Amp) PGM outputs Available Using the PC5204 module
1 PC5204 Output Fully Supervised for Siren Output
Powerful 1.5 Amp Regulated Power Supply:
550 mA Auxiliary Supply, 12 V
DC
Positive Temperature Coefficient (PTC) components replace fuses
Supervision for loss of AC Power, Low Battery
Internal Clock Locked to AC Power Frequency
Power Requirements:
Transformer = 16.5 VAC, 1.5A
Battery = 12 volt 4 Ah minimum rechargeable sealed lead acid
Remote Keypad Specifications:
8 Different Keypads Available:
- PC5508(Z) 8 Zone LED Keypad - PC5532(Z) 32 Zone LED Keypad
- PC5516(Z) 16 Zone LED Keypad - LCD5500 (Z ) Alphanumeric Keypad
Each Keypad has 5 Fully Programmable Function Keys Connect up to 8 Keypads
Four Wire (Quad) Connection to Keybus Built in Piezoelectric Buzzer
“Z” version keypads have zone input
Digital Communicator Specifications:
Supports all Major Formats including SIA and Contact ID and Residential Dial
Split Reporting of Selected Transmissions to Each Telephone Number
3 Programmable Phone Numbers 2 Account numbers
Supports LINKS1000 Cellular Communication DTMF and Pulse Dialing
DPDT Line Seizure Anti-jam Feature
Event-Initiated Personal Paging
System Supervision Features
The PC5015 continuously monitors a number of possible trouble conditions including:
AC Power Failure Trouble by Zone Fire Trouble
Telephone Line Trouble Low Battery Condition Bell Output Trouble
Loss of Internal Clock AUX Power Supply Fault Tamper by Zone
Failure to Communicate Module Fault (Supervisory or Tamper) Camera Troubles via DLM-4L
