11
WLS909-433/WLS919-433: Press any function key at several different locations.
WLS912-433: Press and hold the test mode tab for 5 seconds. Release the test
mode tab. The keypad will display the test result.
Read the test results at the keypad:
Result LED Keypad LCD Keypad Buzzer/Bell
Good Light 1 On Steady “Good” 1 Beep/Squawk
Bad Light 3 On Steady “Bad” 3 Beeps/Squawks
Activate the device until you get 3 ‘good’ results in a row.
You may mount the WLS devices where results were good.
Devices indicating a bad result must be moved to another location. You may
only have to move the device a few inches to correct a bad result.
Do not mount any device where a “bad” test result was indicated.
7. Go to the next device to be tested and activate it until the test result is
displayed/sounded.
NOTE: Wait until the placement test of one device is shown/sounded before begin-
ning to test the next device.
Continue to test the devices until both the PC5132-433 and the devices are in good
locations. If several wireless devices produce ‘bad’ test results, you may need to
move the PC5132-433 to a better location. (See section 2.2 for tips on finding a
location for the PC5132.)
8. To exit the placement test and return to installer programming, press [#] twice.
Testing Individual WLS904P-433, WLS906-433, WLS907-433,
WLS912-433, WLS914-433 and WLS925L-433 Devices:
1. Temporarily place the WLS904P-433, WLS906-433 or WLS925L-433 where
you want to mount it.
2. At a system keypad, enter [✱][8][Installer Code].
3. Enter programming section [904].
4 Enter the 2-digit zone number for the device to be tested.
5. Activate the device being tested until a result is displayed on the keypad or
sounded by the keypad or bell. (Same as step 5 in the Global Placement Test
section, previous page.)
6. To test another device, press [#] once, then repeat steps 4 - 5. Continue to
test the devices until both the PC5132-433 and the devices are in good
locations.
If several wireless devices produce ‘bad’ test results, you may need to move
the PC5132-433 to a better location. (See section 2.2 for tips on finding a
location for the PC5132.)
7. To exit the placement test and installer programming, press [#] twice.
Testing Individual Wireless Keys:
You cannot use the individual device test described above to test WLS909-433/
WLS919-433 wireless keys. To ensure that the PC5132-433 receiver is receiving
transmissions from these devices, use the function keys on the WLS909-433/
WLS919-433 at several different points in the installation.
T E S T I N G & M O U N T I N G
