Self Contained Wireless Alarm System v1.0
26
[406] Number of Rings To Answer On
Default 000 I_______I_______I_______I Valid entries are 000-009, (000 to disable)
[499] Initiate PC-Link Downloading
Enter [499] [Installer Code][499]
[501]-[502] PGM Output Attributes
Program only the following attributes for the PGM options listed. All others will be ignored.
PGM options are programmed in Section [009].
PGM Attribute Defaults (Y = Attribute ON; N = Attribute OFF):
Section PGM Output 1 2 3 4 5 6 7 8
#Type*
Main Board
[501] 1 ( )
I________I I________| I________| I________| I________| I________| I________| I________I
[502] 2 ( ) I________I I________| I________| I________| I________| I________| I________| I________I
*Record here based on programming in Section [009].
Attribute: 12 3 4 5 678
ON
Not used Not used True Output Follows Timer Code Req. Not used Not used Not used
OFF
— — Inverted On / Off No Code Req. — — —
PGM Option
[00] Null PGM (Not Used)
[01] Residential Burglary / Fire Bell Output
Y
[05] System Armed Status
Y
[06] Ready To Arm
Y
[07] Keypad Buzzer follows PGM
Y
[08] Courtesy Pulse
Y
[09] System Trouble (See Table Below) YY Y Y Y YYY
[10] System Event (See Table Below) YY Y Y Y YYN
[11] System Tamper (all sources, zones, keypad, modules)
Y
N
[12] TLM and Alarm
Y
[17] Away Armed Status
Y
[18] Stay Armed Status
Y
[19] Command Output #1, [][7][1]
YYY
[20] Command Output #2, [][7][2]
YYN
Attribute: 123456 7 8
ON
Serv Req
Evnt.
AC Fail. TLM Fault FTC Zone Fault Zone Tamper Zone Low
Batt
Loss of Clock
OFF
Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled
PGM Option
[9] System Trouble
YYYYYYY Y
Attribute: 123456 7 8
ON
Burg Event Fire Event Panic Event Medical
Event
Supervisory
Event
Priority Event Duress Event Follows Timer
OFF
Disabled Disabled Disabled Disabled Disabled Disabled Disabled Latched
PGM Option
[10] System Event
YYYYYYY N
