7.2 Programming Worksheets
25
[381] Second Communicator Options
[382] Third Communicator Options
*This option must remain OFF for SIA-FAR installations.
** A Call Waiting Cancel on a non-Call Waiting line will prevent successful connection to the central station.
DLS Downloading
[401] Downloading Options
[402] DLS Downloading Telephone Number (32 Digits)
|____D__|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|_______|
[403]-[404] DLS Downloading Access Code / Panel ID Code (Enter 6 Hexadecimal Digits)
Opt Def. ON OFF
1
Opening After Alarm Keypad Ringback Enabled
Disabled
2
Future Use
3
SIA Uses Programmed Reporting Codes
SIA Uses Automatic Reporting Codes
4
Closing Confirmation Enabled
Closing confirmation Disabled
*5
Talk/Listen on Phone #1/3 Enabled
Talk/Listen #1/3 Disabled
*6
Talk/Listen on Phone #2 Enabled
Talk/Listen #2 Disabled
7
Contact ID Uses Programmed Reporting Codes
Contact ID Uses Automatic Reporting Codes
8
Future Use
*These Options apply to SCW9047 Only. For SCW9045 default is OFF
Opt Def. ON OFF
1
Contact ID Partial Closing Identifier is “5”
Contact ID Partial Closing Identifier is “4”
2
Alarm Communications Enabled During Walk Test*
Alarm Communications Disabled During Walk Test
3
Communication Cancelled Message Enabled (ON for SIA CP-01)
Communication Cancelled Message Disabled
4
Call Waiting Cancel Enabled**
Call Waiting Cancel Disabled
5
Future Use
6
AC Failure Transmission Delay is in Hours
AC Failure Transmission Delay is in Minutes
7
Number of Dialing Attempts is 1 for Residential Dial
Residential Dialing Attempts is 5
8
Future Use
Opt Def. ON OFF
1
Answering Machine/Double Call Enabled
Answering Machine/Double Call Disabled
2
User Can Enable DLS Window
User Cannot Enable DLS Window
3
Call Back Enabled
Call Back Disabled
4
User Initiated Call Up Enabled
User Initiated Call Up Disabled
5
Future Use
6
300 Baud Panel Call up
110 Baud Panel Call up
7
Future Use
8
Future Use
[403] Downloading Access Code [404] Panel ID Code SCW9045 Default = 904500/904500
SCW9047 Default = 904700/904700
|_______|_______|_______|_______|_______|_______| |_______|_______|_______|_______|_______|_______|
