DStv 5-2 - Connecting to Two DStv Exploras

Connecting the DStv Switch (5-2) to two DStv
Exploras
• Once the switch has been connected to the satellite dish, use the supplied
cable and connect output A to the input labelled UNICABLE™ IN on the
back of the first DStv Explora. Then connect output B to the input labelled
UNICABLE™ IN on the back of the second DStv Explora.
• Then check and change the Home Network Settings as below :
H/L V/L H/H V/H
1 2 3 4
A
B
DStv Explora
1
DStv Explora
2
9
DStv Switch - User Guide
DStv Explora 1
Home Network Settings
(No change – retain defaults)
Tuner 1 Frequency 0
Tuner 2 Frequency 1
Tuner 3 Frequency 2
Tuner 1 Index 1210
Tuner 2 Index 1420
Tuner 3 Index 1680
DStv Explora 2
Home Network Settings
Tuner 1 Frequency 3
Tuner 2 Frequency 4
Tuner 3 Frequency 2
Tuner 1 Index 1892
Tuner 2 Index 2040
Tuner 3 Index 1680
