No Name Options Description
4 Temperature Green
Yellow
Red
An indication of the temperature of the FPGA. Try to
keep it green.
0°C to 59°C shown in green.
60°C to 84°C shown in yellow.
85°C or above shown in red.
CAUTION: If it changes to red, switch the unit off
and allow it to cool.
>95°C some video encoder functionality is
disabled to try and reduce temperature; video
quality will be affected.
>99°C the unit will shut down and restart to avoid
permanent FPGA damage.
5 Logging Greyed – unavailable
White – logging
Logging is normally off by default.
Logging is enabled by using a command line
switch which is fully described in
Section 6.2
.
6 Connect Button Red=disconnected
Green=connected
Click to connect or disconnect the Domo Device
Controller serial connection.
The application will remain open when
disconnected.
