7.2 Pinout – SOL7TX
7.2.1 16-Way Hirose
Pin Signal Name
1 12V In
2 GND
3 RS232 Ctrl Tx
4 RS232 Ctrl Rx
5 1V8 GPIO
6 RS232 Data Rx
7 Ext PA Enable
8 Chain Clk I/O
9 GND
10 Chain Data I/O
11 Audio In R
12 GND
13 Audio In L
14 GND
15 Comp Video 1
16 Comp Video 2
