Group: DVB-T Mod
Command Command Name Type R/W Scope Options
o1ba DVB-T bandwidth intList Config 0 = 6MHz
1 = 7MHz
2 = 8MHz
o1co DVB-T constellation intList Config 0 = QPSK
1 = 16-QAM
2 = 64-QAM
o1fe DVB-T FEC rate intList Config 0 = 1/2
1 = 2/3
2 = 3/4
3 = 5/6
4 = 7/8
o1gu DVB-T guard interval intList Config 0 = 1/32
1 = 1/16
2 = 1/8
3 = 1/4
o14k DVB-T 4k offset intList Config
0 = None
1 = +4kHz
2 = -4kHz
o1dp DVB-T dual pedestal intList Config
0 = No
1 = Yes
o1sp DVB-T spectrum polarity intList Config
0 = Norm
1 = Inv
Group: Misc
Command Command Name Type R/W Scope Options
mpat Pattern generator control intList Config 0 = Disabled
1 = Force on
2 = Auto video/audio
3 = Auto video
4 = Auto audio
5 = AV sync
mgrp SDI embedded audio group intList Config 0 = 1(0xFF/0xE7)
1 = 2(0xFD/0xE6)
2 = 3(0xFB/0xE5)
3 = 4(0xF9/0xE4)
