DTS 500 - Pre-Flight Controls Test

22
Pre-Flight Controls Test
1.Control Test: Throttle
2.Control Test: Elevator
Push the throttle stick upward till the motor start to spin. Ensure the motor spins anti-clockwisely while the main blade
spins clockwisely.
Please don't push the throttle stick upward over 1/5. The motor will spins at high velocity if the throttle stick is over
pushed. This may cause damage on the product or self injury. Besides flight operation, when performing mainten-
ance or adjustment and fine-tuning indoor, please remove the connection between the motor and the ESC. This
can prevent the motor from unpredictable spinning and cause acidents.
Throttle Position: Right Throttle Position: Left
Swashplate's Back and Front end movement
Throttle Position: Left
Throttle Position: Right
Throttle Position: Left
Throttle Position: Right
Throttle Position: Left
Throttle Position: Right
