12
ELECTRONICS
1. Standard Mode. (No function selected).
When the gate is activated it will open and can be stopped in mid cycle by pressing the
transmitter or manual push button. Pressing the transmitter or push button can reverse the
gate. In standard mode the gate will remain on its open limit until it is triggered to close.
If main power fails, the motor will still operate until battery reaches 9.5 volt. Gate will then
remain closed (Open if condominium mode is selected). Change to manual by overriding
the motor by the override lever. When the main power comes on again, lock in the override
lever and the motor will function as normal.
2. Motor direction change.
By selecting the correct closing direction the motor direction and the limit wires are changed
automatically.
3. Auto close. (Infra red beams must be fitted if auto close is activated).
When Auto close is activated and the Gate opens to the open limit, the gate will wait the
pre-programmed time before automatically closing. If the gate is triggered while the gate is
in its closing cycle it will stop and reopen.
If the transmitter or manual push button is pressed while the gate is in its opening cycle, the
gate will stop and close after the preprogrammed auto close time (from any position, not
only from the open limit)
3a. Party mode. To override the auto close, wait till the gate reaches its open limit then
press & hold the transmitter or manual push button for approximately 4 sec. (The control
card will give 1 long beep to confirm the override) To reactivate the auto close, press and
release the transmitter or manual push button.
4. Condominium/free exit loop.
When condominium/free exit loop is activated on the unit, the unit will not respond to any
transmitter or manual push button while in its opening cycle or open position. When the
gate is on the open limit the unit will automatically wait the pre-programmed auto close
time and then close. (Even if auto close function is not selected). When the gate is in its
closing cycle and the transmitter or manual push button is pressed the gate will stop and
open. Auto close cannot be overridden in condominium mode. (No party mode). If main
power fails, the motor will still operate until battery reaches 9.5 volt. Gate will then remain
open.
Change to manual by overriding the motor by the override lever. When the main power
comes on again, lock in the override lever and the motor will function as normal.
5. P.I.R.A.C (Passive Infra Red Access Control)
With P.I.R.A.C mode activated, if the gate is its opening cycle and the IR beam is activated
the gate will stop and close immediately after the IR beam is clear.
(This will happen even if auto close has not been selected).
(Be aware of this factor should a trailer be in tow!!!!)
6. Slowdown
This distance is programmed on the display.
NOTE –
800mm slow down distance is recommended if the limit is continuously being overrun.
