INDEX PAGE
1)
Default settings & Error Codes and messages 2
2)
Features 3
3)
Gearbox mounting & Gate motor override 4
4)
How set install the limit switch actuators 4
5)
Power connection & Courtesy light connections 5
6)
External connections 6
7)
Programming (Calibrating the motor) 7
8)
Motor direction setting 7
9)
Auto close, Condo mode, PIRAC mode 7 & 8
10)
Pedestrian mode, Auxiliary Relay 8
11)
Alarm mode, Speed settings 9
12)
Load and Collusion settings, Learning in transmitters/remotes 10 & 11
13)
Delete and Master erase transmitters/remotes 11
14)
RUN & GENERAL S
tatus reports 11
15)
T
amper & Anti-hijack/Alarm facility 13
16)
Audio indications & Warnings, List of LED indications 14
17)
Process Control Card (PCB) 15
18)
Trouble shooting 16 to 18
Default settings Error Codes and messages
Factory defaults Default setting Code
Error message
Auto close 10 sec. 90 Mains OFF & Battery voltage below 10.5V
Pedestrian 1 meter/5 sec. 91 Motor timed out.
Auxiliary Relay Gate light 92 No error for this number.
Alarm mode OFF 93 Limit switch error. Check open & close limits.
100-400Kg - Speed, Open 25M/min 94 Collision detected, collision setting to low.
Close 25M/min 95 Motor stall with low current. Check load fuse.
Calibrating 8M/min 96 Motor over current trip, Load setting to Low.
Creep 4M/min 97 Over temperature alarm, Mosfets hot.
400-700Kg - Speed, Open 20M/min 98 Safety beams failed, beams not working.
Close 20M/min 99 Motor current flowing, damaged MOSFET
Calibrating 7M/min
Creep 3M/min
700-1000Kg - Speed, Open 15M/min
Close 15M/min
Calibrating 6M/min
Creep 3M/min
ACC - 100-400Kg 100mm
400-700Kg 200mm
700-1000Kg 250mm
DEC - 100-400Kg 400mm
400-700Kg 800mm
700-1000Kg 950mm
Force settings, 100-400Kg 50%
400-700Kg 80%
700-1000Kg 100%
Collusion, 100-400Kg 50%
400-700Kg 50%
700-1000Kg 65%
