 Pin assignment
PIN
No.
Signal Name
Definition
I/O
Type
(*3)
1, 19
DOCOM
Isolation ground for Digital I/O OUT0 to 4, Pass,
Error, and Run
-
-
2, 20
DOVCC
Power supply of overcurrent protection circuit
-
-
18, 27,
36
DIVCC
Isolation power switch for input
I
B
3
Pass
PASS status output signal
Low: Normal end, Hiz: Other and above
O
A
4
Error
ERROR status output signal
Low: Abnormal end, Hiz: Other than above
O
A
5
RUN
Operation condition output signal
Low: Programming or function execution is currently
being executed Hiz: Other than above
O
A
29
EXT1
EXT1 KEY Pin
I
B
30
EXT2
EXT2 KEY Pin
I
B
31
CLR
RESET KEY Pin/ User clear signal
I
B
34
Digital I/O ST0
Script selection signal 0 (Digital I/O input)
I
B
35
Digital I/O ST1
Script selection signal 1 (Digital I/O input)
I
B
10
Digital I/O ST2
Script selection signal 2 (Digital I/O input)
I
B
11
Digital I/O ST3
Script selection signal 3 (Digital I/O input)
I
B
12
Digital I/O ST4
Script selection signal 4 (Digital I/O input)
I
B
7
Digital I/O ST5
Script selection signal 5 (Digital I/O input)
I
B
8
Digital I/O ST6
Script selection signal 6 (Digital I/O input)
I
B
9
Digital I/O ST7
Script selection signal 7 (Digital I/O input)
I
B
13
Digital I/O IN0
Digital I/O input signal 0
I
B
14
Digital I/O IN1
Digital I/O input signal 1
I
B
15
Digital I/O IN2
Digital I/O input signal 2
I
B
16
Digital I/O IN3
Digital I/O input signal 3
I
B
28
Digital I/O IN4
Digital I/O input signal 4
I
B
6
Digital I/O
OUT0
Digital I/O output signal 0
O
A
21
Digital I/O
OUT1
Digital I/O output signal 1
O
A
22
Digital I/O
OUT2
Digital I/O output signal 2
O
A
23
Digital I/O
OUT3
Digital I/O output signal 3
O
A
24
Digital I/O
OUT4
Digital I/O output signal 4
O
A
32
STEP
Step execution input signal
I
B
33
START
Script signal loading trigger input signal
I
B
17, 25,
26
Reserved
-
-
