47
Signal description（Probe Connector）
Signal description (CAN communication)
Below shows description of I/O signal from target side during CAN communication
(”I/O” means input and output direction from view of probe side.)
Signal
Name
Meaning I/O Type
TVCCS User power monitor input I A
CANH
High level signal for CAN communication I/O B
CANL
Low level signal for CAN communication I/O B
TIO
I/O terminal (definition varies according to definition program) I/O C
TMODE
I/O terminal (definition varies according to definition program) I/O C
PROBE SELECT Terminal selection signal of target probe I D
Reserve Reserve signal (do not connect anything from target side) － －
GND GND － －
pin
No
Signal Name definition I/O
1
RX1+ Received data 1 + Input I
2
RX1- Received data 1 - Input I
3
TX1+ Send data 1 + Output O
4
TX1- Send data 1 - Output O
5
Reserved Reserved signal line -
6
Reserved Reserved signal line -
7
PWR Power O
8
GND GND -
