With BOOST active, the LED’S
current is set to Max value.
(30% more gain compared to
BOOST Off)
Default = Enabled
Up-Down
MENU
ENTER
Up-Down
ENTER
Up-Down
Up-Down
Up-DownENTER
ENTER
ENTER
Up-Down
Up-Down
Up-Down
ENTER
Up-DownENTER
Up-DownENTER
Up-DownENTER
ENTER
ENTER
ENTER
ENTER
LED
Led Min/Max, Smooth, Compression,
Sync and Boost level values settings
LED MINIMUM VALUE
This menu allow to select the minimum
levels for white
LED MAXIMUM VALUE
This menu allow to select the maximum
levels for white
These settings have priority
on Master Dimmer channel
SMOOTH VALUE
This menu allow to select the value of
the delay (in milliseconds) for Dimmer
channel reaction to DMX or Program
variation.
Off = 25 ms. Instant response to DMX
variation.
20 = 250 ms. Smooth response to DMX
variation.
COMPRESSION
This menu allow to select between
Linear current output or Quadratic
current output for LEDs
Default = Quadratic
SYNC
This menu allow to adjust the PWM
frequency value (Hz) in order to reduce
flickering in the process of your camera
recordings
BOOST DRIVING
This menu allow to increase the LED’s
current from Min to Max
Linear = Linear
Current output
Quadratic =
Linear light
output
Default = 0
Default = 100
Range = Off-20
Default = 4
Range = 610 Hz – 10
KHz
Default = 610 Hz
Boost mode
activated
Boost mode
deactivated
MENU
Up-Down Up-DownENTER
ENTER
ENTER
INFRARED MODE
Infrared remote control.
By activating Ir Mode, it will be
possible to navigate trought the unit
functions by using the D.T.S.
infrared remote control
(D.T.S. Code: 0514L008)
Note:
External infrared remote
sensor needed (D.T.S. Code:
03.LA.016)
NOT IMPLEMENTED ON SCENA LED 150
